Mango Power M
Whole-Home Backup Energy System
Launch Time: June 12th
Specification
M Hybrid Inverter 12kW Parameters | Table header 1 |
---|---|
Weight | 119.9Ibs (54.4kg) |
Size | 20.4x10.5x31.0inches (519*267*787mm) |
M Hybrid Inverter 12kW Parameters | Table header 1 |
---|---|
Weight | 119.9Ibs (54.4kg) |
Size | 20.4x10.5x31.0inches (519*267*787mm) |
AC - On-Grid Power Parameters | |
Maximum continuous AC output power | 12000VA/240V &10400VA/208V |
Peak power | 24000VA 500ms |
Grid-tied power factor | 0.8leading-0.8lagging adjustable |
Nominal AC output voltage | 120V/240V/208V |
Voltage range | 180V-270V |
Maximum continuous AC current | 50A |
Nominal frequency | 60Hz |
Extended frequency range | 55-65Hz |
Maximum AC output over current protection | 75A |
Max efficiency | 97.5%(PV to grid) 94%(battery to grid) |
THDI | <3% |
Cooling | Low noise Fans |
AC - Backup Output Power Parameters | |
Maximum continuous AC output power | 12000VA/240V & 10400VA/208V |
Peak power | 24000VA 500ms |
Nominal AC output voltage | 120V/240V/208V |
Voltage range | 180V-270V |
Maximum continuous AC current | 50A |
Nominal frequency | 60Hz |
Extended frequency range | 55-65Hz |
Maximum AC output over current protection | 75A |
Max efficiency | 97.5%(PV to grid) 94.0%(battery to grid) |
THDV | <3% |
Bypass grid switching time | <20ms |
Maximum AC output over current | 200A |
DC-PV Parameters | |
PV modules power | 18000W |
MPPT numbers | 3 max power point trackers (two strings combined) |
MPPT voltage range | 120V-500V |
Full power MPPT voltage range | 230V-500V |
Maximum input DC voltage | 600V |
Maximum input current | 25/15/15A |
Maximum DC input short circuit current | 31/19/19A |
MPPT efficiency | 99.90% |
M Smart Screen | |
WiFi Dongle | 2.4G connection,802.11b/g/n |
Connection | HDMI |
Screen Size | 4.3 inches |
M Battery 5kWh Parameters | |
Battery chemistry | World's best LFP battery powered by CATL |
Capacity | From 15kWh/300Ah to 20Wh/400Ah with four M Battery packs |
Battery DC voltage range | 44V-60V |
Max charging current | Super-fast continuous charging speed, up to 1C for battery pack. 250A for 15000Wh and 20000Wh |
Max discharging current | 250A (for at least 3 M Battery packs) |
Roundtrip efficiency | 97.00% |
Weight | 103.6lbs(47Kg) |
Size | 22.9x5.2x15.2 in (581x133x387mm) |
Battery Working Temperature | Charging:32°F~140°F (0°C~60°C ) Discharging: -4°F~140°F (-20°C~60°C) |
Life Span | 6000 cycles(@25℃, +0.5C/-0.5C) |
M Cabinet Parameters | |
Environmental category/UV expose rating | NEMA Type 4X/IP65 outdoor |
Capacity | From 1~4 M Battery packs |
Weight | 114.2lbs (51.8kg) |
Size | 31.5x15.4x46.3in (800x390x1182mm) |
Cabinet installation | M-slide-a-way for easy installation |
Features and Certification | |
RSD/AFCI | PV rapid shut down integrated |
Integrated disconnection | DC switch |
Grid-following | Grid-tied |
Grid-forming | Micro-grid |
Certification | CA rule21 UL1741/IEEE1547/UL1973/UL1642/UL9540&UL9540A |
Generator | Smart control by AGS(Auto Generator Start)10800W for generator ,120V Maximum 90A |
Home backup | Whole and partial home backup |
Smart control | MANGO POWER App download from APP Store or Google Play |
System design | AC coupled and DC coupled |
Grid type | 120V/240V/208V Split-phase L1,L2,N,PE(single phase) |
Inverter Working Temperature | -13℉ to 140℉>113℉ derating(-25℃ to 60℃>45℃ derating) |
Size | 36.4x23.7x11.9in (925.6*606*301mm) for M Power Hybrid Inverter, 31.5x15.4x46.3in (800x390x1182mm) for M Cabinet |
Weight | 119.9Ibs (54.4kg) for M Power Hybrid Inverter, 103.6lbs (47Kg) for M Battery, 114.2lbs (51.8kg) for M Cabinet |
Installation | Ground placed and slightly wall mounted |
Noise | <50dB ( Do not install Power M next to the wall of bedroom) |
Environmental category/UV expose rating | NEMA type 4X/IP65 outdoor rated |
Relative humidity | 0%-100%(condensing) |
Altitude | <2000m |
Warranty | The product retains 70% of its available capacity within 6 months after the date of manufacture or 10 years after the date of completion of installation and commissioning |
AC - On-Grid Power Parameters | Table header 1 |
---|---|
Maximum continuous AC output power | 12000VA/240V &10400VA/208V |
Peak power | 24000VA 500ms |
Grid-tied power factor(adjustable) | 0.8leading-0.8lagging adjustable |
Nominal AC output voltage | 120V/240V/208V |
Voltage range | 180V-270V |
Maximum continuous AC current | 50A |
Nominal frequency | 60Hz |
Extended frequency range | 55-65Hz |
Maximum AC output over current protection | 75A |
Max efficiency | 97.5%(PV to grid) 94%(battery to grid) |
THDI | <3% |
Cooling | Low noise Fans |
AC - Backup Output Power Parameters
| Table header 1 |
---|---|
Maximum continuous AC output power | 12000VA/240V & 10400VA/208V |
Peak power | 24000VA 500ms |
Nominal AC output voltage | 120V/240V/208V |
Voltage range | 180V-270V |
Maximum continuous AC current | 50A |
Nominal frequency | 60Hz |
Extended frequency range | 55-65Hz |
Maximum AC output over current protection | 75A |
Max efficiency | 97.5%(PV to grid) 94.0%(battery to grid) |
THDV | <3% |
Bypass grid switching time | <20ms |
Maximum AC output over current | 200A |
DC-PV Parameters
| Table header 1 |
---|---|
PV modules power | 18000W |
MPPT numbers | 3 max power point trackers (two strings combined) |
MPPT voltage range | 120V-500V |
Full power MPPT voltage range | 230V-500V |
Maximum input DC voltage | 600V |
Maximum input current | 25/15/15A |
Maximum DC input short circuit current | 31/19/19A |
MPPT efficiency | 99.90% |
M Smart Screen
| Table header 1 |
---|---|
WiFi Dongle | 2.4G connection,802.11b/g/n |
Connection | HDMI |
Screen Size | 4.3 inches |
M Battery 5kWh Parameters
| Table header 1 |
---|---|
Battery chemistry | World's best LFP battery powered by CATL |
Capacity | From 15kWh/300Ah to 20Wh/400Ah with four M Battery packs |
Battery DC voltage range | 44V-60V |
Max charging current | Super-fast continuous charging speed, up to 1C for battery pack. 250A for 15000Wh and 20000Wh |
Max discharging current | 250A (for at least 3 M Battery packs) |
Roundtrip efficiency | 97.00% |
Weight | 103.6lbs(47Kg) |
Size | 22.9x5.2x15.2 in (581x133x387mm) |
Battery Working Temperature | Charging:32°F~140°F (0°C~60°C ) Discharging: -4°F~140°F (-20°C~60°C) |
Life Span | 6000 cycles(@25℃, +0.5C/-0.5C) |
M Cabinet Parameters
| Table header 1 |
---|---|
Environmental category/UV expose rating | NEMA Type 4X/IP65 outdoor |
Capacity | From 1~4 M Battery packs |
Weight | 114.2lbs (51.8kg) |
Size | 31.5x15.4x46.3in (800x390x1182mm) |
Cabinet installation | M-slide-a-way for easy installation |
Features and Certification
| Table header 1 |
---|---|
RSD/AFCI | PV rapid shut down integrated |
Integrated disconnection | DC switch |
Grid-following | Grid-tied |
Grid-forming | Micro-grid
|
Certification | CA rule21 UL1741/IEEE1547/UL1973/UL1642/UL9540&UL9540A |
Generator | Smart control by AGS(Auto Generator Start)10800W for generator , 120V Maximum 90A |
Home backup | Whole and partial home backup |
Smart control | MANGO POWER App download from APP Store or Google Play |
System design | AC coupled and DC coupled
|
Grid type | 120V/240V/208V Split-phase L1,L2,N,PE(single phase) |
Inverter Working Temperature | -13℉ to 140℉>113℉ derating(-25℃ to 60℃>45℃ derating) |
Size | 36.4x23.7x11.9in (925.6*606*301mm) for M Power Hybrid Inverter, 31.5x15.4x46.3in (800x390x1182mm) for M Cabinet |
Weight | 119.9Ibs (54.4kg) for M Power Hybrid Inverter, 103.6lbs (47Kg) for M Battery, 114.2lbs (51.8kg) for M Cabinet |
Installation | Ground placed and slightly wall mounted |
Noise | <50dB ( Do not install Power M next to the wall of bedroom) |
Environmental category/UV expose rating | NEMA type 4X/IP65 outdoor rated |
Relative humidity | 0%-100%(condensing) |
Altitude | <2000m |
Warranty | The product retains 70% of its available capacity within 6 months after the date of manufacture or 10 years after the date of completion of installation and commissioning |
We reserve the right to make technical changes. The values, outputs, other technical data, images, and diagrams in this prospectus and in data sheets, advertisements, and other promotional documents are approximate guidelines in all cases where they have not been identified as binding.
